Model Overview
 23" WMC Wallmate Spec Sheet |
 32" DMQ/DHP Spec Sheet |
 36" SCE/SCH/SCW Spec Sheet |
 37" 16 Series Spec Sheet |
 45" Chromalox CDF - Specs CSD/CSU - Specs |
Cooling Capacity |
|---|---|---|---|---|
| 9,300 BTUH | 9,800 - 14,300 BTUH | 9,600 - 14,400 BTUH | 9,600 - 14,000 BTUH | 12,200 - 15,700 BTUH |
| Heating Capacity | ||||
| Cooling Only | Up to 5.0kW (17,300 BTUH) | Up to 5.1kW (17,400 BTUH) | Up to 4.1kW (14,300 BTUH) | Up to 7.5kW (26,000 BTUH) |
| Heating Options | ||||
| Cooling Only | Electric Resistance (DMQ) Heat Pump (DHP) Cooling Only |
Electric Resistance (SCE) Heat Pump (SCH) Hydronic (SCW) Cooling Only |
Electric Resistance | Electric Resistance |
| Sleeve Dimensions | ||||
|
23" wide by 15 9/32" high (Can be used in sleeves up to 26 5/8" wide by 16 11/16" high with Trim Kit.) |
32" wide by 18 5/16" high | 36" wide by 16" high 40" wide by 16" high 42" wide by 16" high |
37 1/2" wide by 16" high 41 1/2" wide by 16" high |
45 1/8" wide by 16" high |
| Power | ||||
| 115V/1/60Hz 15A |
230-208V/1/60Hz 277-265V/1/60Hz 15-30A |
230-208V/1/60Hz 277-265V/1/60Hz 15-30A |
208V/1/60Hz 240-208V/1/60Hz 277V/1/60Hz 15-30A |
208V/1/60Hz 240-208V/1/60Hz 30-50A |
| Energy Efficieny Rating (EER) | ||||
| 8.8 | Up to 10.0 | Up to 9.2 | Up to 10.0 | Up to 9.8 |
| Control Options | ||||
| Standard | Standard Electronic Intermittent Mechanical Remote |
Standard Electronic Intermittent Mechanical Remote |
Electronic | Standard Remote |
| Accessories | ||||
| 23" Sleeve Trim Kit |
32" Sleeve Steel Grille Aluminum Grille Sleeve Extension Kit Remote Thermostat Kit Intermittent Fan Kit Sub-base Duct Kit Duct Extension Kit |
40" Sleeve Steel Grille Aluminum Grille Flange Kit Intermittent Fan Kit |
N/A | N/A |
| Replaces | ||||
| Beaumark 77905 Carrier 51KZ Electrohome AW905 Sears Kenmore C938-354392 |
Carrier Wallmate 51 P Fedders Islandaire EZ CS Heil-Quaker C-Series KeepRite Seasonall McQuay TPW Whirlpool AVT ZoneAire CHP ZoneAire Climette ZoneAire CSM |
Climatemaster 702/703 Cool Heat RM Embassy Weathertwin Fedders Islandaire EZ CM Fedders Islandaire EZ HQ Fedders Islandaire EZ RM Heil-Quaker SHA Heil-Quaker SEA Sears 867 TPI Ra-Matic ZoneAire RM ZoneAire SC ZoneAire SEA ZoneAire SHA |
American Air Filter Series 16 AAF Series 16 AAF Enersaver Nelson Air Series 16 Adirondack-Aire Series 16 Singer Series 16 Remington Series 16 Islandaire 16 McQuay ENR, NES, WY Simon-Aire SS16 RetroAire RC10, RC16 |
Chromalox Space Command: SC-U-DF SI SI-DF SHP SHP-DF |
